| 응답 시간: | +20 → -20 TD : 5S [45S], -20 → -60 ℃ TD : 10S [240S] | 해결: | 이슬점 : 0.1 point 또는 0.1ppm |
|---|---|---|---|
| 가스 유량: | 0.25 3 0.35L/분 | 압력 측정: | 0 a 1.0mpa |
| SF6 순도 범위: | 0 6 100% SF6 | 정확성과 반복성: | 유량과 무관하게 ± 0.1% |
| SF6 Humidity | |
| Measurement Range | Dew point: -80～+20℃ (Supports ppmv, etc.) |
| Dew Point Accuracy | ±1℃ (When the dew point temperature is lower than 0℃, the sensor output is the frost point) |
| Response Time | 63％[90％] +20→-20℃ Td: 5s[45s] -20→-60℃ Td: 10s[240s] |
| Resolution | Dew point: 0.1℃ or 0.1ppm |
| Gas Flow Rate | 0.25～0.35L/min Equipped with an electronic mass flowmeter No impact from the sample gas flow rate |
| Pressure Measurement | 0～1.0MPa |
| Probe Protection | Stainless steel sintered filter screen |
| SF6 Purity | |
| Range | 0～100% SF6 |
| Accuracy and Repeatability | ±0.1%, independent of flow rate |
| Response Time | 30S |
| SF6 Decomposition Products | |
| SO2 | Measurement range: 0～100ppm Accuracy: ≤±0.5% |
| Sensitivity | 0.1 ppm |
| Repeatability | ≤±1% |
| General Part | |
| Operating Voltage | 220VAC±10%, 50Hz. Both AC and DC available. Overcharge protection. Continuous working time is not less than 5 hours. |
| Storage Temperature Range | -40～+70℃ |
| Output Interface | Compliant with USB1.1 specification |
| Data Storage | Can store 200 records |
| Operating Environment | Temperature: -30～+60℃ Pressure: 0～20bar Sample Gas Flow Rate: No impact |
| Other Configurations | Standard version management software, including report printing and commonly used humidity conversion toolkit |
| Dimensions | 132×283×308 (presumably in mm, if not, please clarify the unit) |
![High-Performance SF6 Gas Tester [KS30-3]: Accurate Detection of Humidity, Purity & SO₂ for Reliable Power Equipment Maintenance 0](/images/load_icon.gif){kind=icon}
Selection of KS30 Series Comprehensive Testers
| Model | Purity | Dew Point | SO₂ | H₂S | CO | HF | Equipped with Recycling Function |
|---|---|---|---|---|---|---|---|
| KS30 | √ | √ | √ | √ | √ | ||
| Ks30-6 | √ | √ | √ | √ | √ | √ | |
| KS30-3 | √ | √ | √ | ||||
| KS30-T | √ | √ | √ | ||||
| KS30-TC | √ | √ | √ | √ | |||
| KS30-CS | √ | √ | |||||
| KS30-4 | √ | √ | √ | √ | |||
| KS30-C3 | √ | √ | √ | √ | |||
| KS30-C4 | √ | √ | √ | √ | √ | ||
| KS30-C | √ | ||||||
| kS30-R-* | √ |
SF6 comprehensive testers, except for a few commonly used models, are basically modular customized.
We will provide customized services based on customer needs.
